Create High Resolution Photography with Point and Shoot Camera on NN3 MKII wRD16 Tripod Head

Create High Resolution Photography with Point and Shoot cameras using the NN3 MKII w/RD16 panoramic tripod head.

The NN3 MKII pano head replaced with the Nodal Ninja 3 "MK3" spherical tripod head.
Nodal Ninja direct link to the NN MK3:
Level: Amateur - Semi Pro.
Lenses: 8mm - 50mm focal length
Features: Compact, Inexpensive, Durable
Popular Uses: Real Estate, Travel, Hobbyist, Amateur, Google Street View
Cameras: Compact, Micro Four Thirds, smaller DSLR's

The "standard" rotator uses reversible brass detent rings that give the sound and feel of click stops. Having these different click stops allows the user to select how many degrees of rotation between shots. Available detent rings include 3, 4, 5, 6, 7, 8, 10, 14, 15, 18, 20, & 24 stops. NN3-MKII has won the Editor's Choice Award, Gold Award, Pixelmania Award, 5 out of 5 ratings from Chasseur d'Images and Applelinks.

This model is best suited for those on the go, a popular choice for Real Estate photographers, hobbyists, hikers and travelers alike. Use for single row and even multi-row. Produce stunning super high resolution panoramas with your point and shoot camera or smaller DSLR's. You can also mount your camera in both landscape (horizontal) and portrait (vertical) orientation.

Size - very small and compact making it easy to carry and stow (see specifications).
Weight: 1lb 1oz (475 grams).
FULL rotation up and down and all-around.
Fits almost all point and shoot cameras from ultra compact to compact and many smaller DSLR's using smaller lenses.
Part in a series of Fanotec's new top of the line CNC machined advanced rotators. These rotators combine high precision, ease of use, compactness, light weight and durability. The inner ball bearing construction also provides for very fluid rotation. You can now change click stops on-the-fly. The RD16 has 16 different click options.

Made from imported premium quality aluminum alloy.
Precision CNC machined components.
Lubricated bearings for smooth rotation.
Laser engraved markings.
Detent interval (click stop) option can be changed on the fly.
More than 10 kg (22lbs) loading supported.
Detent interval can be changed in seconds on the fly.
Knob for locking rotation.
Retainer wire so you don't lose the knobs.
Ideal for making HDR panos and/or mosaics.
Great in windy locations.
Small nadir footprint.
Small nadir footprint diameter of 62mm.
The unique placement of knobs means that they will never appear in the spherical panos.
Fine 2.5 degree rotation markings for making high resolution mosaics.
Compact and light weight - only 347 grams.
16 different degree stop increments (with equivalent number of stops around) include:
3.75 (96 stops)*
5 (72 stops)*
6 (60 stops)*
7.5 (48 stops)
10 (36 stops)
12 (30 stops)
15 (24 stops)
18 (20 stops)*
20 (18 stops)
24 (15 stops)
30 (12 stops)
36 (10 stops)
45 (8 stops)
60 (6 stops)
90 (4 stops)
120 (3 stops)
*Requires dual detent plungers.
Note: The 16-35mm Nikkor lens is not compatible with both the NN3 and NN4 series pano heads.
The Canon EF 8-15mm is very long for a fisheye and may require use of T-30-III T-adapter which gives a bit of added adjustment length.

This panorama head is called the Nodal Ninja 3 series which is designed to be compact and lightweight.
Compatible with our up and coming Automatic Pan Tilt Modules for auto rotation and shooting. Shoot single row or multi-row full spherical panoramas.
If you would like to shoot the nadir (down shot or footprint) purchase NN3 MKII nadir adapter (F9125)). The NA allows you to easily swing the vertical assembly allowing camera to point straight down to the ground.
